Inspyre EVO Disk Complete Race Bike 2024 - Polished Blue

The Evo Disk has been designed to provide the ultimate machine for advancing and improving in competition. This bike is intended for intermediate riders seeking to better their riding and performance. For each bike size, the components are selected to best suit the user's morphology and provide maximum support on the track.

The bike is built around the Inspyre Bicycles® Evo Disk frame, incorporating all the features of a high-end BMX Race frame. Hydroformed tubes made of 6061-T6 aluminium ensure an excellent weight-to-performance ratio. Its geometry allows it to be both stable and responsive. The frame includes the Inspyre Bicycles® Swell rear dropouts. In addition to adding rigidity to the rear of the frame, these dropouts allow for the integration of the Pride Racing® disc brake mount while offering perfect chain tension.

The Evo Disk is fully decked out with high-end "aftermarket" parts. It features the Forward® Joyride 6061-T6 aluminum crankset, the excellent Forward® Joyride V2 hubs with 100% sealed bearings. The rear hub incorporates a 6-pawl system with 150 engagement points that rivals high-end hubs on the market.

In this 2024 version, the Evo is equipped with high-performance Tioga Powerblock tires, considered by many the benchmark in BMX race tyre performance.

The Evo Disk is a bike ready to tackle races, but above all, ready to win.

Features

INSPYRE BICYCLES® Aluminum 6061-T6 Frame
SHIMANO® MT401/410 disc brake kit
TIOGA® Powerblock tires
PRIDE RACING® integrated or semi-integrated headset (ZS or IS, depending on bike sizes)
Swell rear dropouts with integrated chain tensioners
100% sealed bearings
FORWARD® BSA bottom bracket
FORWARD® Joyride V2 rear hub - 150 points of engagement - 6-pawl system - 100% sealed bearings
KMC® Z-1 Chain

Specification

FRAME: Inspyre Evo Disk Cruiser - 21.85’’ - Premium Aluminum 6061-T6 - Hydroformed tubes - Triple butted - Swell forged 3D dropouts
FORK: Inspyre Evo 24" - 100% Chromoly - 1-1/8" Pivot - Tapered legs
HEADSET: Pride Racing - Tapered Integrated - Sealed bearings - IS42 | IS52
HANDLEBAR: Inspyre Evo - 100% CrMo - 5.5’’ x 27.5’’ - BS: 7° / US: 1.5° - 22.2mm
GRIPS: Forward Lock On 130mm - Kraton
STEM: Forward - Top Load - Aluminum 6061-T6 - 50mm
BRAKE LEVER: Shimano BL-MT401 - Right lever - Black
BRAKE CALIPER: Shimano BR-MT410 - Rear caliper - Post Mount - Resin pads
DISC: Forward 140mm disc
BOTTOM BRACKET: Forward external BSA - Sealed bearings
CRANKSET: Forward Joyride AM 2-piece - 4-bolt (104 BCD) - 175mm
PEDALS: Aluminum 9/16
SPROCKET: Aluminum 4-bolt 41T
CHAIN: KMC® Z-1 - 1/2’’ x 3/32’’
COG: 18T - 1/2’’ x 3/32’’ - Chromoly
FRONT RIM: Forward Joyride 24" - Aluminum 36H - Double-wall
REAR RIM: Forward Joyride 24" - Aluminum 36H - Double-wall
FRONT TIRE: Tioga Powerblock - 24x1.75’’ - Wire bead - 60 TPI
REAR TIRE: Tioga Powerblock - 24x1.60’’ - Wire bead - 60 TPI
FRONT HUB: Forward Joyride V2 - Aluminum body - 36H - 10mm - 100% Sealed bearings - Female bolts
REAR HUB: Forward Joyride V2 Disc - Aluminum cassette body - 36H - ISO 6 - 100% Sealed bearings - 150 points of engagement - 6-pawl system - Female bolts 10mm
SPOKES: Stainless 14G
NIPPLES: Brass 14G
SEAT: Combo Saddle Nylon Seatpost - Seat: 214x113mm - Seatpost: 162x27.2mm
SEAT CLAMP: Forward AM - 31.8mm
TENSIONERS: Integrated Swell Dropouts
WEIGHT: 10,11kg
